Erfurt 1250 ton Mechanical Press

Manufacturer: Erfurt/Germany
Model and Type: PKZV I 1250 FS

Single Action Mechanical Double Sided Press

with Frontside Moveable Table and Cushion in the Table

Manufacturer: Erfurt/Germany

Model and Type: PKZV I 1250 FS

Year of construction: 1985

Condition: good working condition

Technical Specification

Number of Connecting points of the ram: 4

Max. ranm force: 1250 tons

Slide stroke: 630 mm

Slide adjustment: 630 mm

Max. shutheight between bolster plate and slide (stroke down, adjustment up): 1250 mm

Bed area: 4000x2500 mm

Slide area: 3950x2500 mm

Opening in the bed: 3320x1540 mm

Distance between the Columns(L-R): 4050 mm

Cushion capacity: 250 tons

Cushion stroke: 250 mm

Ejection Force: 40 tons

Strokes per minute: 11

Overload protection

Main drive: 132 kW

Height above floor: 9700 mm

Features: Sliding bolster, 2 cushions in slide
